Basic Information

Other Names Metal Raschig Ring
Place of Origin Jiangxi China (Mainland)
Metal Raschig RingSince 1914 when F.Raschig invented this type of ring for tower packing, random tower pickings have been developed extensively. The R-ring is now used in many applications, but particularly in supporting catalyst beds. Metal Raschig Rings are available in a wide range of carbon and stainless steels, 304, 304L, 410,316, 316L etc.Geometric ParametersSize (mm)Bulk density (kg/m3)Number per m3Surface area (m2/m3)Free volume (%)15×15×0.33792300003509525×25×0.4318510002169625×25×0.5400510002209535×35×0.8430190001509350×50×0.5203650010697.450×50×0.7285650010896.450×50×0.832570001099576×76×0.821218306997.380×80×1.23001600659690×90×1.023611606297

Delivery terms and packaging

Packaging Detail: Cartons, palletized+plastic film bag, other package as customers' request. Delivery Detail: Within a week after recevial of the related payment.
Port: Shanghai

Payment term

Letter of credit

Telegraphic transfer
